Stainless Steel Plate 316L

316L stainless steel, also called marine grade stainless steel, is used primarily for its increased resistance to corrosion.

chromium-nickelmolybdenum austenitic stainless steel
Standard:ASTM, ASME, BS, DIN, EN
Technique:Hot rolled,Cold rolled
Quick delivery and standard exporting package
OEM/ODM

Send Inquiry

Description

Stainless Steel Plate 316L is a commonly used stainless steel plate, mainly composed of chromium, nickel, molybdenum and other elements.

Molybdenum is a particularly important element in 316L steel, improves the316L material's resistance to chloride pitting and general corrosion,which makes it a popular choice in applications where the material will come into contact with saltwater or other corrosive substances.

As a low-carbon variant of 316 stainless steel, 316L is primarily used to improve corrosion resistance.Due to the low carbon content.316L plate has superior resistance to stress corrosion cracking (SCC).Moreover,the additional addition of nitrogen further improves its mechanical properties and ensures that it meets industry standards for strength and durability.

316L plate has the characteristics of corrosion resistance, high temperature resistance, wear resistance, etc., and is widely used in aviation, chemical industry, pharmaceutical, marine and other fields.

316L SS Plate

Stainless Steel 316L Sheet Specification

Product	316L Stainless Steel Plate Sheet
Material	201,304,304L,316,316L,321,310S,309S ,202, 430, 409L ,444, 410s, 904L, 2205, 2507,etc
Standard	ASTM,AISI, ASME,SUS,JIS,EN,DIN,BS,GB,etc
Certification	ISO,SGS, BV
Brand	JISCO, LISCO, TISCO ,BAO STEEL, POSCO/ ZPSS,etc
SIZE	thickness:0.3mm-50mm
	width:1000mm, 1219mm, 1250mm, 1500mm, 1800mm, 2000mm, or as your requirement
	Length: 2000mm, 2438mm ,2500mm ,3000mm ,3048mm, 5800mm, 6000mm ,or as your requirement
Surface Finish	NO.1,2B, BA,SB,8K (Mirror), HL, No.4, Sand Blasting ,Embossed, Etching. etc.
Technique	Cold rolled /Hot rolled
Price Terms	Ex-Work,FOB,CIF,CNF,CFR .etc
Payment terms	L/C / TT / or as required
Package	Standard export packing or as per customer's request.
Port of Loading	Shanghai,Tianjin,Qingdao Port,or as request

316L Steel Equivalent Grades

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
SS 316L	1.4404 / 1.4435	S31603	SUS 316L	316S11 / 316S13	03Ch17N14M3 / 03Ch17N14M2	Z3CND17-11-02 / Z3CND18-14-03	X2CrNiMo17-12-2 / X2CrNiMo18-14-3

SS 316 316L Chemical Composition

Element	SS 316L
C	0.035 max
Mn	2.0 max
Si	1.0 max
P	0.045 max
S	0.030 max
Cr	16 – 18
Ni	10 – 14
Mo	2 – 3
Fe	68.89 min

316L Steel Sheets Mechanical Properties

Tensile Strength ksi (min)	Yield Strength 0.2% ksi (min)	Elongation %	Hardness (Brinell) MAX	Hardness (Rockwell B) MAX
70	25	40	217	95

316L Stainless Steel Plate Surface Finish

316L Stainless Steel Sheets are available in various surface finishes, including 2B (cold-rolled, annealed, and pickled), No. 4 (brushed finish), and others, depending on the specific requirements of the application.

316l stainless sheet

316L Plate Processing Service

316L steel sheets has been precision processed, has good surface quality and flatness, and is easy to cut, bend and weld,has great advantages in factory production, engineering assembly and machining.
