SUS201 stainless steel pipe refers to a pipe made from 201 stainless steel, which is a specific grade of stainless steel known for its combination of corrosion resistance, formability, and cost-effectiveness.
Type 201 is an austenitic chromium- nickel-manganese stainless steel that was developed originally to conserve nickel. In the Type SS201 material composition, manganese and nitrogen are partially substituted for nickel.It provides properties similar to Type 301 and can be used in most applications for Type 301.201 steel can be used in many applications because of its wide range of mechanical properties in the annealed and cold worked condition. Type 201stainless is non-magnetic in the annealed condition but becomes magnetic as a result of cold working.
201 stainless steel pipe is a type of tubing material that is widely used in a variety of industries due to its high resistance to corrosion and heat. This tube is made from an alloy that is composed of nickel, chromium, and manganese, which are all highly resistant to rusting and other forms of chemical damage.
SS201 Stainless Steel Pipe Specification
|
Production Name |
SS201 Stainless Steel Pipe |
|
Production Size |
Outer Diameter:6-2000 mm |
|
Product Standard |
ASTM A240,ASTM A312,ASTM A666 |
|
Material Grade |
Mainly 201,304,304L,304H,316,316L,316Ti,2205,330,630,660,409L,321,310S,410,416,410S,430,347H,etc |
|
Welding Line Type |
ERW,EFW,Sprial Weleded,Seamless (All can be customized as customer's requirements) |
|
Surface |
BA, 2B, 2D, 4K, 6K, 8K, NO.4, HL, SB, Embossed |
|
Advantage |
We have stock, about 20000 tons. |
|
** The sizes or thicknesses of stainless steel can be customized, if you need additional information,please don’t hesitate to |
|
|
If your quantity is smaller than our MOQ, kindly pls contact us for inquiry accordingly, sometime we have small stock, thank you. |
|
201 Steel Seamless Pipe Size
| NPS | OD | SCH 5S | SCH 10S | SCH 40S | SCH 80S |
| 1/4 | 13.72 | – | 1.65 | 2.24 | 3.02 |
| 3/8 | 17.15 | – | 1.65 | 2.31 | 3.2 |
| 1/2 | 21.34 | 1.65 | 2.11 | 2.77 | 3.73 |
| 3/4 | 26.67 | 1.65 | 2.11 | 2.87 | 3.91 |
| 1 | 33.4 | 1.65 | 2.77 | 3.38 | 4.55 |
| 1.25 | 42.16 | 1.65 | 2.77 | 3.56 | 4.85 |
| 1.5 | 48.26 | 1.65 | 2.77 | 3.68 | 5.08 |
| 2 | 60.33 | 1.65 | 2.77 | 3.91 | 5.54 |
| 2.5 | 73.03 | 2.11 | 3.05 | 5.16 | 7.01 |
| 3 | 88.9 | 2.11 | 3.05 | 5.49 | 7.62 |
| 3.5 | 101.6 | 2.11 | 3.05 | 5.74 | 8.08 |
| 4 | 114.3 | 2.11 | 3.05 | 6.02 | 8.56 |
| 5 | 141.3 | 2.77 | 3.4 | 6.55 | 9.53 |
| 6 | 168.28 | 2.77 | 3.4 | 7.11 | 10.97 |
| 8 | 219.08 | 2.77 | 3.76 | 8.18 | 12.7 |
| 10 | 273.05 | 3.4 | 4.19 | 9.27 | 12.7 |
| 12 | 323.85 | 3.96 | 4.57 | 9.53 | 12.7 |
| 14 | 355.6 | 3.96 | 4.78 | 9.53 | 12.7 |
| 16 | 406.4 | 4.19 | 4.78 | 9.53 | 12.7 |
| 18 | 457.2 | 4.19 | 4.78 | 9.53 | 12.7 |
| 20 | 508 | 4.78 | 5.54 | 9.53 | 12.7 |
| 22 | 558.8 | 4.78 | 5.54 | – | – |
| 24 | 609.6 | 5.54 | 6.35 | 9.53 | 12.7 |
| 26 | 660.4 | – | – | – | – |
| 28 | 711.2 | – | – | – | – |
| 30 | 762 | 6.35 | 7.92 | – | – |
SS201 Material Chemical Composition
| Element | Content (%) |
| Iron, Fe | 72 |
| Chromium, Cr | 16.0 – 18.0 |
| Manganese, Mn | 5.50 – 7.50 |
| Nickel, Ni | 3.50 – 5.50 |
| Silicon, Si | 1.0 |
| Nitrogen, N | 0.25 |
| Carbon, C | 0.15 |
Type 201 Stainless Steel Yield Strength
| Properties | Metric | Imperial |
|---|---|---|
| Density | 7.86 g/cm3 | 0.284 lb/in³ |
Stainless 201 Mechanical Properties ASTM A312
| Type | Yield Strength 0.2% offset (KSI) | Tensile Strength (KSI) | % Elongation (2" Gauge length) |
Hardness Rockwell |
| SS 201 Ann | 38 min. | 75 min. | 40% min. | HRB 95 max. |
| SS 201 ¼ Hard | 75 min. | 125 min. | 25.0 min. | 25 – 32 HRC (typical) |
| SS 201 ½ Hard | 110 min. | 150 min. | 18.0 min. | 32 – 37 HRC (typical) |
| SS 201 ¾ Hard | 135 min. | 175 min. | 12.0 min. | 37 – 41 HRC (typical) |
| SS 201 Full Hard | 145 min. | 185 min. | 9.0 min. | 41 – 46 HRC (typical) |
