Alloys 309 and 309S are austenitic chromium-nickel stainless steels developed for use in high temperature corrosion resistance applications. The only significant difference between 309 and 309S is the carbon content.
309 (UNS S30900) stainless steel is an austenitic heat resistant alloy with oxidation resistance to 1900°F under constant temperature conditions.309S (UNS S30908) is the low carbon version of the alloy.
The 309/309S stainless steel plate is distinguished by its high chromium and nickel content, providing superior resistance to oxidation and corrosion in challenging environments. The high chromium content contributes to its excellent resistance to sulfidation and other aggressive chemical reactions, making it an ideal choice for applications in elevated temperature atmospheres.
SS309 Chemical Composition
| Element | 309 | 309S |
| Chromium | 22.0 min.-24.0 max. | 22.0 min.-24.0 max. |
| Nickel | 12.0 min.-15.0 max. | 12.0 min.-15.0 max. |
| Carbon | 0.20 | 0.08 |
| Manganese | 2.00 | 2.00 |
| Phosphorus | 0.045 | 0.045 |
| Sulfer | 0.030 | 0.030 |
| Silicon | 0.75 | 0.75 |
| Iron | Balance | Balance |
309 Stainless Steel Plate Specification
|
Items |
Stainless Steel Sheet/Stainless Steel Plate |
||||
|
Standard |
AISI ,ASTM, DIN, JIS, GB, JIS, SUS,EN, etc |
||||
|
Technique |
Hot rolled/Cold rolled |
||||
|
Length |
4m-12m or as required |
||||
|
Width |
0.6m-3m or as required |
||||
|
Thickness |
0.1mm-300mm or as required |
||||
|
Surface Treatment |
Clean blasting and painting according to customer requirement |
||||
|
Export Packing |
Waterproof Paper, Steel Strip Packed and other Standard Export Seaworthy Package, or customized package |
||||
|
Supply Ability |
5000 Ton/Tons per Month |
||||
|
Certification |
CE, ISO, SGS, BV |
||||
309 Stainless Steel Sheet Surface Finish
309 Stainless Steel sheet is available in various surface finishes, including 2B (cold-rolled, annealed, and pickled), No. 4 (brushed finish), and others, depending on the specific requirements of the application.
Stainless Steel Plate FAQ
Q: Are you trading company or manufacturer?
A: We are factory.
Q: Do you provide samples? is it free or extra?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: Can you OEM or ODM?
A: Yes, we have a strong development team. Stainless Steel Plate Products can be produced according to your requirements.
Q:What port you mainly export?
A: Export from Tianjin/Qingdao/Shanghai port,any port in China is available.
Q:How's the package?
A:Standard export sea-worthy packaging, the inner layer has a waterproof paper outer layer with iron packaging and is fixed with a fumigation wooden pallet. It can effectively protect products from corrosion and various climate changes during ocean transportation.
