S460QL high tensile steel plate belongs to the European standard high-strength steel sheet and complies with the European standard EN10025-6,which is equal to Chinese steel grade Q460E.
S460QL high yield strength steel plate can achieve a yield strength greater than 460MPa after quenching and tempering. The low temperature impacting test for high strength steel plate S460QL should be done at minus 40 centigrade.
EN 10025-6 S460QL Steel Plates Specification
| Grade | S460QL |
| Number | 1.8906 |
| Classification | Alloy special steel with specified minimum values of impact energy at temperatures not lower than -40 ° C |
| Thickness | 3-300mm |
| Width | 4500-4050mm |
| Length | 3000-15000mm,or as requirement |
| Heat treatment | Q and T |
S460QL Steel Chemical Properties
| C | Si | Mn | Ni | P | S | Cr | Mo | V | N | Nb | Ti | Cu | Zr | B | CEV |
| max 0.2 | max 0.8 | max 1.7 | max 2 | max 0.02 | max 0.01 | max 1.5 | max 0.7 | max 0.12 | max 0.015 | max 0.06 | max 0.05 | max 0.5 | max 0.15 | max 0.005 | max 0.5 |
S460QL Mechanical Properties
| Thickness (mm) | |||
| S460QL | ≥ 3 ≤ 50 | > 50 ≤ 100 | > 100 |
| Yield strength (≥Mpa) | 460 | 440 | 400 |
| Tensile strength (Mpa) | 550-720 | 550-720 | 500-670 |
