304L stainless steel plate belongs to the austenitic stainless steel family and is one of the most widely used and widely used stainless steel plate varieties.Known for its excellent corrosion resistance, versatility and durability, 304L stainless steel is a lower carbon variant of standard 304 stainless steel with better corrosion resistance. It prevents intergranular corrosion by reducing the carbon content. This material maintains good corrosion resistance at high temperatures and has been widely used in many applications.
The "L" in stands for "Low," indicating a lower carbon content, typically around 0.03% or lower, compared to the higher carbon content in Grade 304 stainless steel.The low carbon content in 304L minimizes carbide precipitation during welding, which helps to maintain corrosion resistance and strength in the heat-affected zones of welded joints.
304L Steel Chemical Composition
| Element | 304 | 304L |
| Chromium | 18.0 min.-20.0 max. | 18.0 min.-20.0 max. |
| Nickel | 8.0 min.-10.5 max. | 8.0 min.-12.0 max. |
| Carbon | 0.08 | 0.030 |
| Manganese | 2.00 | 2.00 |
| Phosphorus | 0.045 | 0.045 |
| Sulfer | 0.030 | 0.030 |
| Silicon | 0.75 | 0.75 |
| Nitrogen | 0.10 | 0.10 |
| Iron | Balance | Balance |
304L Stainless Steel Plate Specification
| Specifications | ASTM A240 / ASME SA240 |
| Standard | ASTM, ASME and API |
| Thickness | 4.0mm – 100mm |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | SS 304L, (UNS S30403) |
304L Material Equivalent
| JIS G4304 | ASTM | UNS | KS | EN10095 | AS | CNS |
| SUS304L | 304L | S30403 | STS304L | 1.4306 | 304L | 304L |
304L Steel Mechanical Properties
| Element | SS 304L |
| Density | 8.0 g/cm3 |
| Melting Point | 1400 °C (2550 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
304L Sheet Available Surface
304L stainless steel plate can also provide different sizes and surface treatments according to customer needs, such as No.1, 2B, BA, NO.4, 8K, etc.
304L Plate Processing Service
304L stainless steel is a high-quality, durable and corrosion-resistant material,and can be processed by deep drawing, drilling, shearing and extrusion as needed.
