Wear Resistant Manganese Steel Plate Mn13
Mn13 steel is made by adding manganese to low-carbon steel, resulting in a harder and tougher alloy than ordinary steel. The addition of manganese also increases the wear resistance, corrosion resistance, and impact resistance of steel.
This type of steel has high wear resistance, which means it can withstand the worst working conditions and remain intact for a longer period of time. Despite its high hardness, it can be easily formed and welded, allowing for the production of customized components tailored to specific applications. Its high strength and toughness also give it crack and deformation resistance, allowing it to maintain its shape and function in harsh environments.
Mn13 Steel Plate Specification
| Item | MN13 Steel |
| Width | 1000-3000mm,or as requirments |
| Standard Grade | DIN : 1.3401, XAR400, XAR300, XAR450, XAR600, XAR500, X120Mn12 EN : QUARD450, QUARD400, QUARD500; RAEX320, RAEX500, RAEX400 NF : FORA500, FORA400,; Creusabro8000, Creusabro4800 GB : NM360, Mn13, NM600, NM400, NM450, NM500, NM550 JIS : JFE-EH400, JFE-EH360, JFE-EH500; WEL-HARD500, WEL-HARD400 |
| Delivery State | controlled rolling, hot-rolled, normalizing, tempering, annealing, quenching, N+T, Q+T |
| Thickness | 2-300mm,or as requirments |
| Surface | clean, blasting, finishing, and painting |
| Length | 1000-12000mm,or asrequirements |
Mn13 Steel Chemical Composition
| Grade | Mn | C | S | Si | P |
| Mn13 | 11.00 - 14.00 | 0.090 - 1.020 | ≤0.030 | 0.030 - 0.080 | ≤0.035 |
Mn13 Mechanical properties
|
Grade |
Tensile Strength |
Reduction |
Impact property20°C |
Initial hardness value(HB) |
Hardness value after hardening (HB) |
|
Rm(Mqa) |
of area A(%) |
||||
|
Mn13 |
≥800MPa |
≥40% |
ak≥90(J) |
200-250 |
>300 |
Production capacity:10,000 tons per month
MOQ:1 pc
Packing details:Standard Seaworthy Packing, or according to customers' requirements.
Port: Qingdao,Tianjin,Shanghai,etc.
1) 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
2) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
3) 40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High)
