Description

316L stainless steel is a high-quality stainless steel material with high corrosion resistance and high temperature resistance. The material is suitable for the manufacture of various equipment and appliances, such as pressure vessels, petrochemical equipment, food processing equipment, medical devices, etc. It can also be used in harsh environment applications such as Marine equipment and chemical equipment.

The following are the product specifications of 316L stainless steel:

1. Chemical composition:
C: ≤0.03%
Si: ≤1.00%
Mn: ≤2.00%
P: ≤0.035%
S: ≤0.030%
Ni: 10.0%-14.0%
Cr: 16.0%-18.0%
Mo: 2.0%-3.0%

2. Physical properties:
Density: 7.98g /cm3
Melting point: 1398-1422℃
Tensile strength: ≥485 MPa
Yield strength: ≥170 MPa
Elongation: ≥30%

3. Surface treatment:
Matte surface, bright surface, sanded surface

4. Standard size:
Thickness: 0.3-120mm
Width: 1000-2500mm
Length: 2000-6000mm

In short, 316L stainless steel has many excellent properties and a wide range of applications, it is a reliable material choice, with great market potential.
