Grade 304 is the most used standard grade has good corrosion resistance and good machinability,consist of iron, chromium (Cr), nickel (Ni) and other alloy elements,while the chromium content is about 18-20% and the nickel content is about 8-10%,gives the 304 stainless steel pipe excellent corrosion resistance and mechanical properties.
SS 304 Tube maintain good strength and oxidation resistance in the temperature range under 800°C.In addition,304 stainless steel pipe has good corrosion resistance in most environments, especially in general atmosphere and mildly corrosive media.However, in marine environments with high chloride ion content, rust spots may appear on the surface of 304 stainless pipes, but this will not affect its performance and corrosion resistance.
JBLSTEEL is a leading manufacturer and supplier of the Stainless Steel Pipe available in different types, shapes and methods. There are different grades and specifications such as the Grade 304, 316,201 and the Standard A312,A269,A249,etc.The Stainless Steel Pipe Price ranges depending mostly on the grade of the material.Please feel free to contact us for more information on the Stainless Steel Tube products and pricing.
The stainless steel pipe has a smooth and flat surface, which is not easy to accumulate scale. The smooth and flat performance and non-adhesive properties ensure that the pipeline has a stronger transportation level than traditional pipes, and at the same time reduces the pressure loss and transportation energy consumption of the pipeline
Stainless Steel tube Specification
|
Product Name |
Stainless steel pipe |
|
Standard |
ASTM,AISI,DIN, EN,GB,JIS |
|
Steel Grade |
200 Series: 201,202 |
|
Outer Diameter |
6-2500mm(as required) |
|
Thickness |
1mm-150mm (as required) |
|
Length |
2000mm/2500mm/3000mm/6000mm/12000mm(as required) |
|
Types |
Seamless/Welded |
|
Surface |
No.1,2B,BA,6K,8K,Mirror,No.4,HL |
|
Tolerance |
±1% |
|
Technique |
Cold Rolled,Hot Rolled |
|
Color |
Natural Color/Customized |
|
Price Terms |
FOB,CFR,CIF,or Negotiation |
Stainless Steel Pipe Price
JBLSTEEL is one of the most competitive suppliers of pipes and tubes from China.Our prices for Stainless Steel Pipes Tubes are very competitive.
Please click on the request a quote button or click here to request the updated price list and ready stock information along with your requirement. JBLSTEEL maintains a stock of all standard items and can export them at best competitive price for Stainless Steel Seamless and Welded Pipes.
Stainless Pipe Chemical Composition
| Grade | UNS | C | Mn | P | S | Si | Cr | Ni | Mo |
| TP304 | S30400 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-11.0 | |
| TP304L | S30403 | 0.035 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-13.0 | |
| TP316 | S3160 | 0.08 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 |
| TP316L | S31603 | 0.035 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
SS Tube Mechanical Properties
| Material | Heat Treatment |
Temperure | Tensile Strength | Yield Strength | Elongation %, Min |
| Min. | Ksi (MPa), Min. | Ksi (MPa), Min. | |||
| º F(º C) | |||||
| TP304 | Solution | 1900 (1040) | 75(515) | 30(205) | 35 |
| TP304L | Solution | 1900 (1040) | 70(485) | 25(170) | 35 |
| TP316 | Solution | 1900(1040) | 75(515) | 30(205) | 35 |
| TP316L | Solution | 1900(1040) | 70(485) | 25(170) | 35 |
SS Pipe Valued Service
We offer value-added services including polishing, annealing, heat treatment, and beveling for our SS Pipes.
Process Service:Bending,Welding,Decoiling,Punching,Cutting,Moulding
Stainless Steel Pipe Surface Finish
Details:2B,2D,BA,NO.1,NO.4,NO.8,8K,mirror,checkered,embossed,hair line,sand blast,brush.
Multiple specifications are available.
JBLSTEEL-Company Profile
HENAN JINBAILAI INDUSTRIAL CO.,LTD. was established in 2008,and it is an integrated steel manufacturing company that produces and sells alloy and stainless steel products,we supply various sepcifications of Stainless Steel,Super Stainless Steel,Super Duplex,High Strength Steel Plate,Wear Resistant Steel Plate, Galvanized Steel,etc.
The inventory is sufficient and various,supporting processing and customization.For general information about our Stainless Steel Pipe or a free quote, do contact us.
