S960QL high-strength steel plate is a high-strength steel material with extremely high strength, toughness and corrosion resistance. It is widely used in construction, machinery, aviation and aerospace, military industry and other fields.
S960QL is a water quenched and tempered steel that in compliance with EN10025:6,a high yield strength structural steels in the quenched and tempered delivery state.Compared with ordinary low carbon steel and medium carbon steel, S960QL steel plate is more durable and more risk-resistant.
S960QL High Strength steel sheet Specification
Standard:EN 10005-6
Thickness:6mm-200mm
Width:1500mm-4200mm
Length:3000mm-18000mm
Heat Treatment:Quenched and Tempered
Package:Standard export seaworthy packing or as required.
Port:Shanghai,Tianjin,Qingdao port,or as requirement
S960QL Carbon Equivalent
|
Steel Grade |
Thickness(mm) |
carbon equivalent(%) |
|
S960Q/S960QL WQ960D/WQ960E |
10~30 |
≤0.56 |
|
31~60 |
≤0.61 |
S960QL Steel Properties
| Grade | Chemical composition %, max | |||||||||||
| C | Si | Mn | P | S | B | Cr | Cu | Mo | Nb | Ni | Ti | |
| S960QL | 0.22 | 0.86 | 1.8 | 0.03 | 0.017 | 0.006 | 1.6 | 0.55 | 0.74 | 0.07 | 2.1 | 0.07 |
| Mechanical properties, min | ||||||||||||
| Yield strength (Mpa) | Tensile strength (Mpa) | Elongation | ||||||||||
| Thk>3≤50 | >50≤100 | >100≤150 | >3 ≤50 | >50≤100 | >100≤150 | 10% | ||||||
| 960 | ~ | ~ | 980-1150 | ~ | ~ | |||||||
S960QL Steel Plate Additional Services
- Low temperature impacting test
- Quenching and Tempering heat treatment
- Ultrasonic test
- Shot blasting and Painting,Cutting and welding as per requirements
